    Simple Workflow for Intraoperative Histology

    The NIO Imaging System is designed to streamline intraoperative histology, reducing downtime in the OR and allowing examination of specimens from multiple sites in the surgical cavity


    Biopsy

    • Use standard biopsy tools
    • Sample multiple sites in the surgical cavity

    Prepare Specimen

    • One-step squash preparation


    • Fully-automated image acquisition
    • 2-3min per high-resolution image
    • Interface designed to handle multiple specimens

    Collaborate

    • PACS export
    • DICOM query/retrieve

    Examples of Stimulated Raman Histology (SRH)

    Normal Cortex

    Glioma

    Meningioma

    Metastatic Carcinoma

    Pituitary Adenoma

    Lymphoma

    Images are for illustration only. Patient diagnosis was established by traditional means.

    ​

    References:

    Orringer et al., Nature Biomedical Engineering 1, 27 (2017)

    Hollon et al., Cancer Research 78,1 (2017)

    Picture Archiving System (PACS) Integration

    QUERY / RETRIEVE

    EXPORT

    OPERATING ROOM

    PACS

    INTERPRETATION

    Technical  Specifications

    Proprietary label-free imaging technology to provide magnified, depth-resolved tissue images

    Data format: DICOM

    Imaging speed: 16 MPixel in 2-3min (e.g. 2mm x 2mm  tissue specimen in high-resolution mode)

    Network port: isolated gigabit

    ethernet

    Dimensions: 2.2' x  3.1' x 5.2'

    Scan area: up to 10x10mm

    Weight: 360lbs

    Intuitive touch-screen interface

    Power: 120/230V, 50/60Hz, <1500W

    High-resolution touch screen: 1920x1080

    Operating conditions: 10-30C
